Anemos Signature RPH by Facheris Yacht Design MIAMI

MAIN CHARACTERISTICS

BUILDER: HARGRAVE SUPERYACHTS DIVISION

ACCOMODATION: 10 GUESTS + 7 CREW

CLASSIFICATION: Rina or ABS Pleasure Yachts or Commercial Yachts Compliant

LENGTH OVER ALL: 122ft / 37 meters

LENGTH WATERLINE: 112ft / 34 meters

BEAM: 26ft / 7.92 meters

DRAFT: 6.5ft / 1.98 meters

DISPLACEMENT (Light Ship): 150 Tonnes

DISPLACEMENT (Fully loaded): 190 Tonnes

GROSS TONNAGE: 299 GT (Approx.)

SPEED: 25 Knots

PROPULSION

MAIN ENGINES 2 x CAT C32 2200HP @ 2300 Rpm

GEARBOX: ZF3050 SERIES 2,98:1

ENGINE CONTROL: GLENDINING ( 1 main + 2 remote station)

GENERATORS: 2X CAT C4.4 65 KW

SHAFT PROPELLER: CJR (UK) 4,5” MARINEMET 25 Shaft / 5 Blades Class S Propellers

ELECTRIC SYSTEM: 120 / 208 VAC 3P 60Hz Main Service / 24VDC Service and Engine Start System/

ASEA 65 kVA Shore Power Converter/ 2x Glendinning CM9 Cable Master

TANK CAPACITY

Diesel Oil: 20800 Lt / 5.500 Gallons

Fresh Water: 4.000 Lt / 1.000 Gallons

Black Water: 2.000 Lt / 500 Gallons

GreyWater: 2.700 Lt / 700 Gallons

BUILD / CONSTRUCTION

HULL / SUPERSTRUCTURE: CARBON RAINFORCED E-GLASS - EPOXY COMPOSITE SANDWICH

OPEN DECK: HANDLAID BURMESE / MYANMAR TEAK OR NON SKID PAINT

PAINT SYSTEM: AWLGRIP

MASTER EQUIPMENT LIST

Airhorn: Kahlenberg

Anchor winch and Capstans: (x2 )Maxwell VWC6000 Hyd. Windlass, VC4000 Electric Capstans

Windscreen Wipers: (x4) Speich

Alarm & Monitoring system: Wago / Advantech

Anchor and Chain: (x2) 200kg 316L S.S. Pool Anchor, (x2) 110m (360 ft) 14mm Grade 3 Studlink Chain

Audio / Video:RTI

Batteries and chargers: Victron /

Service: 10x 220Ah Gel + 2x 24/100A Charger

Emergency: 4x 220Ah Gel + 1x 24/80A Charger

Radio: 2x 130Ah Gel + 1x 24/30A Charger

ME and Genset: 8x 240Ah AGM + 2x 24/40A Charger

Emergency Fire Pumps: 4x 220Ah Gel + 1x 24/80A Charger

ER Ventilation: Delta T System

Bow thrusters: Sleipner Bow thruster

Stabilizer: Sleipner at Rest Stabilizer with Power Pack

Fuel oil filters: Racor

HVAC: TECHNICOLD

Chiller assembly (x4) 60,000 BTU or 2 x 120,000 BTU

Steering System:Wills Ridley Hydraulic Steering

Insulation: Unifrax B15 Engine room and B0 Galley insulation Rockwool Thermal cabin insulation

Navigation and communication equipment: GARMIN and FURUNO

Pumps: Head Hunter and FEIT

Sewage treatment: Headhunter

Toilet system: Headhunter

Water heaters: TORRID 2x 50 Gallons 6kW

DECK EQUIPMENT

SWIM LADDER: 316L Stainles Steel

CRANE: Hydraulic Deck Crane 1000

PASARELLA: OPACMARE or EQUAL 15ft Hydraulic Gangway

HANDRAILS: 316L S.Steel

PANTOGRAPH DOORS: (x2) Pantograph Door

SLIDING DOORS: Electric Operated main saloon door

WATERTIGHT DOORS AND DECK HATCHES: Watertight Deck Hatches and Engine room WT Fire Doors

AFT BEACH SHELL DOOR: Hydraulic Actuator Operated Carbon Reiforced Composite Watertight Door

SIDE GARAGE SHELL DOOR: Hydraulic Actuator Operated Carbon Reiforced Composite Watertight Door

SAFETY EQUIPMENT

LIFE RAFTS: 2 x 12 Persons

FIRE PROTECTION: FM200 Engine Room Fire Protection

FIRE & GENERAL ALARM SYSTEM: HAES UK

Patrizio Facheris spent thirteen years at Michael Peters Yacht Design before founding Facheris Design, bringing with him a discipline built on proportion, naval engineering, and the conviction that exterior and interior design should be resolved as one decision rather than two separate briefs.

Born in Italy, based in Florida, his perspective sits at the intersection of European design sensibility and North American market knowledge - a combination that few studios can draw on from genuine experience.

Facheris Design delivers exterior styling, interior concept, and naval architecture under one roof. For the Anemos platform, that integrated approach produced a profile that stays low, a superstructure that avoids the stacking that dates a yacht, and an interior resolved from the same design logic as the hull it sits on.
